Medical Tests A-Z

Coronary angiography

Definition

Coronary angiography is a procedure that uses a special dye (contrast material) and x-rays to see how blood flows through the arteries in your heart.

Alternative Names

Cardiac angiography; Angiography - heart; Angiogram - coronary; Coronary artery disease - angiography; CAD - angiography; Angina - angiography; Heart disease - angiography

How the Test is Performed

Coronary angiography is sometimes performed with cardiac catheterization. This is a procedure that measures pressures in the heart chambers.

Before the test starts, you will be given a mild sedative to help you relax.

An area of your body (the arm or groin) is cleaned and numbed with a local numbing medicine (anesthetic). The cardiologist passes a thin hollow tube, called a catheter, through an artery and carefully moves it up into the heart. X-ray images help the doctor position the catheter.

Once the catheter is in place, dye (contrast material) is injected into the catheter. X-ray images are taken to see how the dye moves through the artery. The dye helps highlight any blockages in blood flow.

The procedure most often lasts 30 to 60 minutes.

How to Prepare for the Test

You should not eat or drink anything for 8 hours before the test starts.

You will wear a hospital gown. You must sign a consent form before the test. Your health care provider will explain the procedure and its risks.

Tell your provider if you:

  • Are allergic to any medicines or if you have had a bad reaction to contrast material in the past
  • Are taking sildenafil (Viagra), vardenafil (Levitra), tadalafil (Cialis) or other medicines from this class
  • Might be pregnant

How the Test will Feel

In most cases, you will be awake during the test. You may feel some pressure at the site where the catheter is placed.

You may feel a flushing or warm sensation after the dye is injected.

After the test, the catheter is removed. You might feel a firm pressure being applied at the insertion site to prevent bleeding. If the catheter is placed in your groin, you will be asked to lie flat on your back for a few hours to several hours after the test to avoid bleeding. This may cause some mild back discomfort.

Why the Test is Performed

Coronary angiography may be done if:

  • You have angina for the first time.
  • Your angina that is becoming worse, not going away, occurring more often, or happening at rest (called unstable angina).
  • You have aortic stenosis or another valve problem.
  • You have atypical chest pain, when other tests are normal.
  • You had an abnormal heart stress test.
  • You are going to have surgery on your heart and you are at high risk for coronary artery disease.
  • You have heart failure.
  • You have been diagnosed as having a heart attack.

Normal Results

There is a normal supply of blood to the heart and no blockages.

What Abnormal Results Mean

An abnormal result may mean you have a blocked artery. The test can show how many coronary arteries are blocked, where they are blocked, and the severity of the blockages.

Risks

Cardiac catheterization carries a slightly increased risk when compared with other heart tests. However, the test is very safe when performed by an experienced team.

Generally, the risk for serious complications ranges from 1 in 1,000 to 1 in 500. Risks of the procedure include the following:

  • Cardiac tamponade
  • Irregular heartbeats
  • Injury to a heart artery
  • Low blood pressure
  • Allergic reaction to contrast dye or a medicine administered during the exam
  • Stroke
  • Heart attack

Considerations associated with any type of catheterization include the following:

  • In general, there is a risk for bleeding, infection, and pain at the IV or catheter site.
  • There is always a very small risk that the soft plastic catheters could damage the blood vessels or surrounding structures.
  • Blood clots could form on the catheters and later block blood vessels elsewhere in the body.
  • The contrast dye could damage the kidneys (particularly in people with diabetes or prior kidney problems).

Considerations

If a blockage is found, your provider may perform a percutaneous coronary intervention (PCI) to open the blockage. This can be done during the same procedure, but may be delayed for various reasons.

References

Dangas GD, Mehran R. Coronary angiography and intravascular imaging. In: Libby P, Bonow RO, Mann DL, Tomaselli GF, Bhatt DL, Solomon SD, eds. Braunwald's Heart Disease: A Textbook of Cardiovascular Medicine. 12th ed. Philadelphia, PA: Elsevier; 2022:chap 21.

Fihn SD, Blankenship JC, Alexander KP, et al. 2014 ACC/AHA/AATS/PCNA/SCAI/STS focused update of the guideline for the diagnosis and management of patients with stable ischemic heart disease: a report of the American College of Cardiology/American Heart Association Task Force on Practice Guidelines, and the American Association for Thoracic Surgery, Preventive Cardiovascular Nurses Association, Society for Cardiovascular Angiography and Interventions, and Society of Thoracic Surgeons. J Am Coll Cardiol. 2014;64(18):1929-1949. PMID: 25077860 pubmed.ncbi.nlm.nih.gov/25077860.

Kern MJ, Kirtane AJ. Catheterization and angiography. In: Goldman L, Schafer AI, eds. Goldman-Cecil Medicine. 26th ed. Philadelphia, PA: Elsevier; 2020:chap 51.

Werns S. Acute coronary syndromes and acute myocardial infarction. In: Parrillo JE, Dellinger RP, eds. Critical Care Medicine: Principles of Diagnosis and Management in the Adult. 5th ed. Philadelphia, PA: Elsevier; 2019:chap 29.
