Limb plethysmography is a test that compares blood pressure in the legs and arms.
Plethysmography - limb
How the Test is Performed
This test may be done in the health care provider's office or in a hospital. You will be asked to lie with the upper part of your body slightly raised.
Three or four blood pressure cuffs are wrapped snugly around your arm and leg. The provider inflates the cuffs, and a machine called a plethysmograph measures the pulses from each cuff. The test records the maximum pressure produced when the heart contracts (systolic blood pressure).
Differences between the pulses are noted. If there is a decrease in the pulse between the arm and leg, it may indicate a blockage.
When the test is complete, the blood pressure cuffs are removed.
How to Prepare for the Test
Do not smoke for at least 30 minutes before the test. You will be asked to remove all clothing from the arm and leg being tested.
How the Test will Feel
You should not have much discomfort with this test. You should only feel the pressure of the blood pressure cuff. The test often takes less than 20 to 30 minutes to perform.
Why the Test is Performed
This test is most often done to check for narrowing or blockages of blood vessels (arteries) in the arms or legs.
There should be less than a 20 to 30 mm Hg difference in the systolic blood pressure of the leg compared with that of the arm.
What Abnormal Results Mean
Abnormal results may be due to:
Arterial occlusive disease Blood clots
- Blood vessel changes due to diabetes
- Injury to an artery
- Other blood vessel disease (vascular disease)
Other conditions for which the test may be performed:
Deep venous thrombosis
If you have an abnormal result, you may need to have more testing to find the exact site of the narrowing.
There are no risks.
This test is not as accurate as an
The test is noninvasive, and it does not use x-rays or injection of dye. It is also less expensive than an angiogram.
Beckman JA, Creager MA. Peripheral artery disease: clinical evaluation. In: Creager MA, Beckman JA, Loscalzo J, eds. Vascular Medicine: A Companion to Braunwald's Heart Disease. Philadelphia, PA: Elsevier; 2020:chap 18.
Tang GL, Kohler TR. Vascular laboratory: arterial physiologic assessment. In: Sidawy AN, Perler BA, eds. Rutherford's Vascular Surgery and Endovascular Therapy. 9th ed. Philadelphia, PA: Elsevier; 2019:chap 20.
